Factory-Direct Cage Fixed Ladders
Fixed Cage Ladder
Safety-cage fixed ladders with Φ700 hoops, trial-fitted at our factory. OSHA 1910.27, EN ISO 14122-4 & BS 4211 compliant — DoC and structural calcs included.
Cage Hoop Diameter
Cage Start Height
Rung Pitch
Rung Width
Safety Cage Configuration
Fixed Cage Ladder
A fixed cage ladder is a permanently attached vertical ladder wrapped in a cylindrical safety cage of hoops and vertical bars. The cage surrounds the climber from about 2.2 m above the base, keeping the body inside the guard so an accidental slip cannot fall backwards out of the ladder.
- Cage diameter Φ700 mm (27.5″) — standard enclosure width
- Cage hoops start at 2.2 m above the base per EN ISO 14122-4
- 8 vertical bars per hoop set, spaced evenly around the rung line
- Rungs Φ20 mm at 280 mm pitch, 500 mm clear width
Dimensions & Standards
Fixed Cage Ladder Specifications & Dimensions
Standard cage geometry plus custom engineering for height, width, and fall-protection requirements. Every figure below is built into the shop drawing we send for approval.
Factory-Direct, No Middleman
You buy the same export-grade cage ladder we ship to contractors in 50+ countries — no trading-company markup.
| Specification | Standard Range | Custom |
|---|---|---|
| Height | 10 – 25 ft (3 – 7.6 m) | Up to 40 ft engineered |
| Material | Q235B / SS304 / SS316 | Duplex / 6063-T5 AL |
| Rung Diameter | Φ20 mm (0.79″) | Per spec |
| Rung Spacing | 280 mm / 11″ (≤300 mm) | Per project spec |
| Clear Width | 500 mm (19.7″) | Custom width |
| Cage Diameter | Φ700 mm (27.5″) | Custom |
| Cage Start Height | 2.2 m above base | Per standard |
| Hoop Pitch | ≤1,150 mm vertical | Per standard |
| Vertical Bars | 8 per hoop set | Per standard |
| Load Rating | 1.5 kN per rung | Engineered |
| HDG Thickness | 85 – 100 μm (ISO 1461) | Heavier coating |
| Finish | HDG / Pickled / Painted | Electropolish (SS) |
| Fall Protection | Cage or PFAS | Ladder safety system |
Build Options
Fixed Cage Ladder Options & Configurations
Same cage geometry, three material families — plus a PFAS-ready build for projects over 24 ft.
Galvanized Steel Cage Ladder
Q235B structural steel, hot-dip galvanized 85–100 μm. The workhorse for roofs, tanks and plant access.
Stainless Cage Ladder
SS304 & SS316 cage ladders for chemical plants, marine environments, and food processing lines.
PFAS-Ready Cage Build
Cage plus a personal fall arrest rail — the configuration OSHA 1910.27 asks for on ladders over 24 ft.
14 m Bath & Chemical-Plant Cage Ladders
We build HDG cage ladders up to 14 m in one continuous run for electroplating baths, tanks and process vats — with hoops sized to clear pipework and walkway offsets.
Certifications
Compliance & DoCumentation
- OSHA 1910.27 — cage & fall-protection rules
- BS 4211:2005+A1:2015 — safety ladders for permanent access
- EN ISO 14122-4 — permanent means of access, fixed ladders
- AS 1657 — Australian fixed-ladder practice
- Cal/OSHA Title 8
Cage Ladder Document Package
DoC, MTC and structural calcs included — no extra cost, no paywall.
-
Declaration of Conformity (DoC)
-
Material Test Certificates — EN 10204 3.1
-
Structural Calculations (cage & rung loads)
-
Welding Procedure Specifications
-
Surface treatment certificates (HDG per ISO 1461)
Factory-Direct Cage Pricing
Factory-Direct Pricing & 24h Quote
Itemized by material, machining, finishing and packaging. No hidden markup, no middleman.
Custom quotation priced by weight & process. Industry reference: caged ladders ≈ USD 899–1,099/ton.
Cage Anatomy — Standard Build
| Parameter | Standard build | Compliance note |
|---|---|---|
| Cage diameter | Φ700 mm (≈27.6 in) clear internal | EN ISO 14122-4 / BS 4211 envelope |
| Hoops | 40×5 mm flat bar @ 1,500 mm vertical pitch | Weld at arc points, ≤1,150 mm per OSHA legacy |
| Vertical straps | 5 × 30×3 mm bars, spaced ≤240 mm | Welded to every hoop |
| Cage start height | 2.2 m (7–8 ft) above base | Per BS 4211 / EN ISO 14122-4 |
| Top extension | 42 in (1.07 m) above top landing | Guards the exit onto the platform |
| Finish | HDG 85–100 μm (ISO 1461) | Or SS304/SS316 pickled & passivated |
Cage vs PFAS vs LSS — Which Fall Protection to Pick
Climbs of 10–24 ft where your site spec or legacy policy still calls for a cage; UK/EU projects per BS 4211 and EN ISO 14122-4; retrofits onto an existing ladder where a rail cannot be mounted.
New US installs above 24 ft — under OSHA 1910.28 a cage alone is no longer accepted for new ladders, so we fit a rigid rail or cable system with a sliding sleeve for daily multi-user climbing.
Low-frequency maintenance access above 24 ft where the worker wears a full-body harness and lanyard attached to a certified anchorage — anchorage points included in our calcs.
Fixed cage ladder questions
The cage starts 7–8 ft (2.2 m) above the base and extends 42 in (1.07 m) above the top landing, so the exit onto the platform stays guarded.
Hoops are spaced at ≤ 1,150 mm vertical pitch with 8 vertical bars per hoop set, bars spaced ≤ 240 mm apart and welded at the arc points.
No — new US installs above 24 ft need a PFAS or ladder safety system. Existing cages are grandfathered until November 2036.
1.5 kN per rung, with the cage assembly included in the structural calcs that ship with the order.
Yes — we weld hoop sets and vertical bars onto the installed stiles, then re-verify the assembly in a fresh structural calc.
Proven in real facilities
Reference projects are shown by industry, country and scale. Client names are available on request with approval.
National utility projects — 15+ countries
23 documented projects, 2021-2025 · 2025
All standardsEnergy & industrial clients — Global
500+ projects since 2004 · 2004-2025
Full compliance docsLargest single order — Malaysia
60 units in one project · 2021
HDGGet Your Cage Quote
Talk to an Engineer
Send your cage ladder spec — free drawing review and an itemized quote in 24 hours.
Why Cage Builds From Dengtai?
Full Compliance Docs
DoC, MTC, structural calcs included free.
24-Hour Quote
Cage geometry + rung loads reviewed within one day.
Trial-Fitted Shipment
Pre-assembled, dry-fitted and crated for export.
Request a Cage Ladder Quote
