Fixed Ladder Guards.
Matched-fit guards built with your ladder — cage hoops, exit guards and gates. OSHA 1910.23 & DIN 18799-3 ready, docs with every order.
Cage ID
Cage Start Height
Rung Load
85-100μm Coating
Guard Range
Fixed Ladder Guards
Fixed ladder guards protect the climber where a ladder breaks through a floor or meets a landing. We build them as add-ons to a new ladder or as upgrades to an existing one — always matched to your rail width.
Cage Hoop Guards
40 × 5 mm flat hoop bands welded to the rungs at Φ700 mm (≈29 in) inside diameter — the same 29-inch ID used by Cotterman, so spec for spec your guards line up with industry-standard caging.
Exit Guards
Top-of-ladder exit protection per DIN 18799-3 — a full-width guard that guides the climber onto the landing and stops falls at the exit point.
Walk-Through & Gate Guards
Guards with an integrated opening and a self-closing swing gate, with a lockable option — A-Mezz style lockable doors, built to your opening size.
Fixed Ladder Guards Specifications & Dimensions
| Guard Component | Standard Spec | Custom |
|---|---|---|
| Hoop band | 40 × 5 mm flat steel | 50 × 5 mm heavy duty |
| Hoop inside diameter | Φ700 mm (≈29 in) | Up to Φ900 mm |
| Hoop vertical spacing | 350 mm centers | Per project |
| Bottom bell mouth | Flared entry at base | Flare width per spec |
| Exit guard (top) | DIN 18799-3 pattern | Walk-through option |
| Gate-integrated guard | Self-closing swing gate | Lockable option |
| Material | Q235B / SS304 / SS316 | Per environment |
| Finish | HDG 85 – 100 μm | Pickled / painted / electropolish |
Cage hoop dimensions share the Φ700 mm (≈29 in ID) industry convention — same number as the product cage spec, so guards retrofit to Dengtai ladders and standard caged systems.
Order guards with your ladderGuard Options
Ladder Guards Fixed Ladders Options & Configurations
Buy guards as add-ons to a new ladder or as upgrades to an existing installation — same factory, matched fit.
Galvanized Guards
Q235B with 85–100 μm HDG — the standard guard finish for outdoor cages.
Stainless Guards
SS304 & SS316 guards for chemical and marine exposure where HDG will not last.
Aluminum Guards
6063-T5 guards matched to aluminum ladders — lightweight and non-sparking.
Guard Standards
Compliance & DoCumentation (OSHA/BS 4211/EN ISO 14122-4)
- OSHA 1910.23 — Guard & Gate Compliance
- DIN 18799-3 — Exit Guards
- ANSI A14.3 — Cage Guards
- OSHA 1910.27 / BS 4211 / EN ISO 14122-4
- AS 1657 — Australian Compliance
Documentation Package
Every guard order ships with complete documentation — no extra cost, no paywall.
-
Declaration of Conformity (DoC)
-
Material Test Certificates — EN 10204 3.1
-
Structural Calculations
-
Welding Procedure Specifications
-
Surface treatment certificates (HDG per ISO 1461)
Factory-Direct Pricing
Factory-Direct Pricing & 24h Quote
Guards are priced as add-ons or upgrades with factory-direct rates — no middleman, itemized per component.
Guard quotation priced by weight & process. Industry reference: caged ladders ≈ USD 899–1,099/ton.
Common questions
Both — we build guards into new ladders at the factory or supply them as upgrades for an existing ladder, always matched to your rail width.
Cage hoops are spaced at 350 mm centers, welded with 40 × 5 mm flat bands at Φ700 mm (≈29 in) inside diameter.
Every guard order includes the DoC and structural calculations; guards built to OSHA 1910.23 or DIN 18799-3 exit-guard specs ship with the relevant certificate.
Yes — walk-through and gate guards come with a self-closing swing gate and a lockable option, built to your opening size.
Yes — Φ700 mm (≈29 in ID) follows the industry convention used by brands such as Cotterman, so replacement guards line up with existing caging.
Fixed Ladder Guards
Fixed Ladder Guards — Sizes, Materials & Standards
Guards close the gaps around a ladder — the cage around the climb, the exit guard at the landing, and the opening guard at floor level. Each one has a size and a standard behind it.
| Guard type | Standard size / material | Standard |
|---|---|---|
| Cage hoops (cage guard) | Φ700 mm ID, 40 × 5 mm flat steel, Q235B / SS304 / SS316 | ANSI A14.3 / BS 4211 |
| Cage vertical bars | On ≈300 mm centers, full cage height from 2.2 m | ANSI A14.3 / BS 4211 |
| Exit guard hoop | Hoop at landing level, same Φ700 mm cage line | DIN 18799-3 / OSHA 1910.23 |
| Landing opening guard | Guardrail 42″ high + self-closing gate at the opening | OSHA 1910.23 / 1910.28(b)(3) |
| Swing gate | Self-closing, built to opening width (standard 600–900 mm) | OSHA 1910.23(a)(2) / ANSI A1264.1 |
| Lockable access door | Per opening size, with slam latch or padlock hasp | Site security spec |
| Finish | HDG 85–100 µm, pickled, painted, or electropolished SS | ISO 1461 |
Guards are built with the ladder so the fit is exact — same material, same finish, same weld class (ISO 5817 C). They can also be retrofitted: send the opening or cage dimensions and we fabricate a matched guard.
Fixed Ladder Guards — FAQ
Guards are the protective elements around a ladder — cage hoops and bars, exit guard hoops, landing opening guards, and swing gates — sized to the ladder geometry.
Φ700 mm inside diameter (≈29″ ID), made from 40 × 5 mm flat steel, with vertical bars on ~300 mm centers — matching the cage standard used industry-wide.
Q235B carbon steel with HDG 85–100 µm, or stainless SS304/SS316 for corrosive environments — same material as the ladder for a matched finish.
OSHA 1910.23 and 1910.28 for openings and cages, ANSI A14.3 and BS 4211 for cage geometry, DIN 18799-3 for exit guards, ANSI A1264.1 for gates.
Yes — retrofit hoops, exit guards, and swing gates are fabricated to your measured opening and welded or bolted to the existing ladder with the same finish.
Proven in real facilities
Reference projects are shown by industry, country and scale. Client names are available on request with approval.
National utility projects — 15+ countries
23 documented projects, 2021-2025 · 2025
All standardsEnergy & industrial clients — Global
500+ projects since 2004 · 2004-2025
Full compliance docsLargest single order — Malaysia
60 units in one project · 2021
HDGGet Your Quote
Talk to an Engineer
Free drawing review. Itemized quote in 24 hours. No obligation.
Why Work With Dengtai?
Full Compliance Docs
DoC, MTC, structural calcs included free.
24-Hour Quote
Engineering review + itemized quote within one day.
Global Delivery
8–12 containers/month. VCI + ISPM 15 packaging.
