Dengtai Fixed Step Ladders
Fixed Ladder
Stairs
Step ladders since 2004 — 500+ fixed ladder projects shipped. HDG steel step ladders, custom angles, factory-direct with full compliance docs.
Stairs Projects
Countries Exported
Per-Rung Rating
Included
Step ladders, custom angles
Platforms · Mezzanines · Catwalks
Custom Step Angles
Fixed Ladder Stairs
A fixed step ladder is the middle ground between a vertical fixed ladder and a full staircase — treads instead of rungs, at a custom angle that fits the space. When a stair footprint is too big but a ladder is too steep, a fixed step ladder is the answer.
- Custom angles from 60–75° — engineered to your riser, tread and landing geometry.
- Step ladders to any height — with intermediate landings where the run demands it.
- HDG steel step ladders, plus SS304 & SS316 for wet or clean environments.
- Serrated or checker-plate treads — a firmer foot than rungs for regular traffic.
Choosing the Right Access
Fixed Step Ladder Options & Configurations
Three access types, one decision — which fits your space, traffic and budget.
Fixed Ladder
Vertical or near-vertical, 75–90°. Smallest footprint, climber faces the rungs.
Fixed Step Ladder
Steep but walkable, 60–75°. Treads instead of rungs — the space-saving stair alternative.
Stairs
Comfortable 30–45°. Largest footprint — the right choice when floor area allows.
Our engineers help you pick — send the floor-to-floor height and available footprint, and we recommend the fixed step ladder angle and tread configuration.
Step Ladder Materials
Step Ladders to Any Height
HDG steel as standard, stainless where the environment demands it.
HDG Steel Step Ladder
Q235B structural steel with hot-dip galvanized treads — the workhorse for plant and warehouse mezzanines.
SS304 & SS316 Step Ladders
Stainless treads and stringers for food plants, breweries, labs and wash-down areas.
Landing Configurations
Intermediate landings and 90° turn step ladders for tall runs and tight shafts.
Step Geometry
Fixed Ladder Stairs Specifications & Dimensions
Angle, rise and tread pitch are engineered together — every figure lands in the shop drawing we send for approval.
No-Middleman Step Pricing
Factory-direct step ladders, the same export-grade build shipped to 50+ countries.
| Specification | Standard Range | Custom |
|---|---|---|
| Height | 6 – 20 ft (1.8 – 6 m) | Up to 40 ft engineered |
| Angle | 60 – 75° from horizontal | Per footprint |
| Material | HDG Q235B / SS304 / SS316 | Duplex / 6063-T5 AL |
| Tread Type | Serrated / checker plate | Grip-strut |
| Tread Pitch | 225 – 250 mm | Per riser spec |
| Clear Width | 600 – 800 mm | Custom width |
| Load Rating | 1.5 kN (≈337 lbf) per tread | Engineered |
| HDG Thickness | 85 – 100 μm (ISO 1461) | Heavier coating |
| Handrail | Single or both sides | Full guard |
| Fall Protection | Handrail / guard / PFAS | Per standard |
Step Ladder Certifications
Compliance & DoCumentation
- OSHA 1910.23(d) — step ladder & stairway rules for fixed access
- EN ISO 14122-3 — permanent means of access, stairs & step ladders
- BS 4211:2005+A1:2015 — safety ladders for permanent access
- EN ISO 14122-4 — fixed ladder rules where a vertical run is used
- AS 1657 & Cal/OSHA Title 8
Step Ladder Document Package
Full docs with every step ladder order — no extra cost.
-
Declaration of Conformity (DoC)
-
Material Test Certificates — EN 10204 3.1
-
Structural Calculations (tread & handrail loads)
-
Welding Procedure Specifications
-
Surface treatment certificates (HDG per ISO 1461)
Factory-Direct Step Pricing
Factory-Direct Pricing & 24h Quote
Itemized by material, machining, finishing and packaging. No middleman step pricing.
Custom quotation priced by weight & process. Industry reference: caged ladders ≈ USD 899–1,099/ton.
Global Step Ladder Shipping
Built in China, Shipped Worldwide
Step ladders leave pre-assembled, dry-fitted and crated for export.
Common questions
Serrated or chequer-plate steel treads (typically 3 mm), HDG or stainless, welded to the stringers at 45–60°.
Yes — handrails at 42 in and mid-rails are standard on step ladders per OSHA 1910.25, with guardrails on landings.
500 mm clear width between stringers as standard; wider configurations are custom-engineered to your drawing.
Steps rated 1.5 kN concentrated as standard (higher on request), verified by the structural calculation shipped with the unit.
Yes — every unit is trial-assembled in the factory, then split at bolted joints for container shipment with a layout drawing.
Scenario → Configuration Mapping
Ladder-Stair Requirements → Recommended Builds
The angle decides the product: 75° is a fixed ladder, 45–60° is a fixed step ladder, and 30–45° is a stair. Match your space, traffic and load to the combination below.
| Scenario Requirement | Recommended Configuration | Material / Finish |
|---|---|---|
| Tight vertical spaces — shafts, tanks, limited footprint | Fixed ladder at 75°, Φ20 mm rungs at 280 mm, cage or PFAS rail over 24 ft (ISO 14122-4) | HDG Q235B or SS316 |
| Comfortable everyday climbing — platforms, mezzanines, plant rooms | Fixed step ladder at 45–60° with open or closed treads, handrails on both sides, rest platform at the top | HDG Q235B / SS304 |
| Two-way traffic with tools — frequent maintenance access | Wider step ladder with serrated steel treads, mid-landing at half height, dual handrails | HDG, serrated treads |
| Carrying loads or trolleys — stores, workshops, equipment rooms | Stair configuration at 30–45° with 600 mm+ tread depth, landings at every change of direction (ISO 14122-3) | Steel chequer or grating treads |
| Outdoor or washdown exposure — roofs, yards, process areas | HDG 85–100 μm on all members, drainage holes on treads, no water traps in the framing | Q235B, HDG 85–100 μm |
Angle Decides the Tread
Below 75° the rung becomes a tread: at 60–75° we use open step-ladder treads, at 45–60° full treads with handrails, and below 45° a stair with landings. Send your floor-to-floor height and footprint — the angle, and therefore the build, follows.
Combining Ladders, Steps & Stairs
One access route can mix all three: a stair to a mid-platform, a step ladder to a mezzanine, a fixed ladder for the last vertical leg. Platforms and swing gates tie the segments together into one engineered unit.
Standards by Configuration
Stairs follow OSHA 1910.25 and ISO 14122-3; ladders follow OSHA 1910.23(d) and ISO 14122-4; alternating-tread units are permitted at 50–70° under OSHA 1910.25(b). We build and document to the standard that matches your chosen configuration.
Fixed Ladder Stairs Questions
30–75°: fixed stairs at 30–45°, fixed step ladders at 45–60°, and fixed ladders at 75°. Custom angles within these bands are built to your footprint and floor-to-floor height.
Angle and tread. Ladders climb at 75° on rungs; step ladders at 45–60° on treads with handrails; stairs at 30–45° with deep treads and landings. Load, comfort and space each favour a different configuration.
Yes — alternating tread devices are permitted between 50° and 70° under OSHA 1910.25(b), for specific low-traffic applications. We'll confirm your use case against the standard before quoting.
Yes — stair-to-platform, platform-to-step-ladder, and final vertical legs are combined into one engineered access route with landings, guardrails and swing gates, supplied as a single fabricated unit.
OSHA 1910.25 and ISO 14122-3 for stairs, OSHA 1910.23(d) and ISO 14122-4 for ladders, BS 4211 where specified. DoC, MTC 3.1 and structural calcs ship with every order.
Proven in real facilities
Reference projects are shown by industry, country and scale. Client names are available on request with approval.
National utility projects — 15+ countries
23 documented projects, 2021-2025 · 2025
All standardsEnergy & industrial clients — Global
500+ projects since 2004 · 2004-2025
Full compliance docsLargest single order — Malaysia
60 units in one project · 2021
HDGGet Your Step Quote
Talk to Our Step Engineers
Send your floor-to-floor height and footprint — free drawing review and a step ladder quote in 24 hours.
Why Dengtai Step Ladders?
Step Ladder DoCs Included
Full compliance documentation with every order.
24-Hour Step Quote
Angle and geometry reviewed within one day.
500+ Projects Shipped
Step ladders exported worldwide.
Request a Step Ladder Quote
