Factory-Direct No-Cage Ladders
Fixed Ladders Without Cages
No-cage fixed ladders built to your exact height — lighter, simpler, and 20-30% less than caged builds. Compliance docs with every order.
PFAS-Ready Build
Rung Width
Rung Pitch
Rung Load Rating
Why Go Without a Cage
Fixed Ladders Without Cages
A no-cage fixed ladder is a plain vertical or inclined rung ladder mounted straight to the wall or structure. It costs less, weighs less, and fits in narrow shafts where a cage hoop will not clear — and it pairs perfectly with a modern fall-arrest rail.
No-Cage Costs Less
Removing the hoops and vertical bars cuts material and welding time. Factory-direct savings land at 20-30% against a caged build of the same height.
Any Custom Height
We build to your exact height, from a 2 m step-up to a 20 m roof run. No cage means we can ship longer unbroken rung strings.
Fits Tight Spaces
Shafts, stair wells and pipe runs often cannot fit a Φ700 cage. A no-cage ladder with a slide rail clears obstacles a cage cannot.
No-cage costs less. Factory-direct saves 20-30% on your project.
Because you buy from the maker — not a trading company — the no-cage saving is real and itemized on your quote: material, machining, finishing and packaging line by line.
Build Options
Fixed Ladders Without Cages Options & Configurations
Choose the material and add a fall-arrest rail where the height calls for one.
Galvanized Steel No-Cage
Q235B rungs and stringers, HDG 85–100 μm. The budget-friendly workhorse for roofs and plant access.
Stainless No-Cage
SS304 & SS316 without cage for food, pharma and marine — no coating to maintain, easy to wash down.
No-Cage + Fall-Arrest Rail
For ladders over 24 ft, OSHA 1910.28 expects a PFAS or ladder safety system — we fit the rail instead of a cage.
Dimensions & Standards
Fixed Ladders Without Cages Specifications & Dimensions
Send your height — we build to it. Standard rung geometry below, with engineering review for long or high-frequency climbs.
No-Cage, Any Custom Height
From a 2 m step-up to a 20 m roof run — rungs continue unbroken because there are no hoops to interrupt them.
| Specification | Standard Range | Custom |
|---|---|---|
| Height | 2 – 25 ft (0.6 – 7.6 m) | Up to 40 ft engineered |
| Material | Q235B / SS304 / SS316 | Duplex / 6063-T5 AL |
| Rung Diameter | Φ20 mm (0.79″) | Per spec |
| Rung Spacing | 280 mm / 11″ (≤300 mm) | Per project spec |
| Clear Width | 500 mm (19.7″) | Custom width |
| Mounting | Wall / floor / structure | Standoff brackets |
| Load Rating | 1.5 kN per rung | Engineered |
| HDG Thickness | 85 – 100 μm (ISO 1461) | Heavier coating |
| Finish | HDG / Pickled / Painted | Electropolish (SS) |
| Fall Protection | None under 24 ft | PFAS rail over 24 ft |
Certifications
Compliance & DoCumentation
- OSHA 1910.23 — fixed-ladder rung & spacing rules
- OSHA 1910.27 — fall protection above 24 ft
- EN ISO 14122-4 — permanent means of access
- BS 4211 & AS 1657 — rung spacing and clearance
Documentation Per Order
DoC, MTC and structural calcs — the paperwork your EHS team asks for.
-
Declaration of Conformity (DoC)
-
Material Test Certificates — EN 10204 3.1
-
Structural Calculations
-
Welding Procedure Specifications
-
Surface treatment certificates (HDG per ISO 1461)
No-Cage Ladders Worldwide
Exported From Our Factory to 50+ Countries
VCI rust protection, ISPM 15 heat-treated crates, and EXW / FOB / CIF terms. Production 15–25 business days.
No-Cage Pricing
Factory-Direct Pricing & 24h Quote
The no-cage build removes the heaviest welded sub-assembly — you feel that in every line item.
Custom quotation priced by weight & process. Industry reference: fixed ladders ≈ USD 899–1,099/ton.
Common questions
From a 2 m step-up to a 25 ft (7.6 m) standard run — rungs continue unbroken because no hoops interrupt them. Longer climbs are engineered to 40 ft.
Φ20 mm rungs at 280 mm (11 in) spacing, 500 mm (19.7 in) clear width, rated 1.5 kN per rung — uniform spacing through the climb.
Q235B with HDG 85–100 μm (ISO 1461), SS304 or SS316, plus duplex and 6063-T5 aluminum on request.
Wall, floor or structure mounting with standoff brackets where clearance is needed; anchors are sized in the structural calcs.
Quote within 24 hours of your height; production in 15–25 working days after drawing approval, pre-assembled and trial-fitted.
No-Cage Fall Protection Options
Fixed Ladders Without Cages — When It Is Allowed
A cage is one fall-protection option, not the only one. Below 24 ft a plain fixed ladder is enough; above that, a ladder safety system or PFAS takes over — both cheaper and lighter than a cage.
LSS vs PFAS for No-Cage Ladders
Rigid rail or cable with a sliding sleeve on the rungs. Best for daily multi-user climbing — no harness training per climb, automatic engagement, and the rail ships pre-drilled with the ladder.
Full-body harness with lanyard clipped to a certified anchorage point. Best for occasional maintenance access — the lightest and lowest-cost option, with anchorage loads included in our structural calcs.
Less steel, less freight, faster installation, and compliance that follows the modern OSHA rulebook. Factory-direct saves 20–30% on the ladder itself.
Compliance Conditions — When No Cage Is Allowed
| Climb Height | Rule | What We Supply |
|---|---|---|
| Up to 24 ft (7.3 m) | No cage or fall-arrest hardware required | Plain rung ladder, Φ20 mm @ 280 mm pitch, 500 mm wide |
| Over 24 ft — new install (US) | OSHA 1910.28: PFAS or ladder safety system required; cage alone not accepted | Rigid rail or cable LSS, or PFAS anchorage per calcs |
| Over 24 ft (UK / EU) | BS 4211 / EN ISO 14122-4: LSS or cage both accepted | No-cage ladder + LSS rail, or cage version |
| Existing cage ladder | Grandfathered under OSHA until Nov 2036 | Replacement runs built no-cage with LSS |
Fixed ladders without cages — questions
Up to 24 ft (7.3 m) no fall-protection hardware is required by OSHA. Above 24 ft, fit a ladder safety system or PFAS instead of a cage.
Yes — for frequent climbing we recommend a rigid-rail LSS: the sleeve rides the rungs automatically, so the climber stays connected hands-free.
Yes — DoC, MTC 3.1 and structural calcs ship with every order, cage or no cage.
Removing the hoop sets and vertical bars cuts steel weight and freight — combined with factory-direct pricing, projects typically land 20–30% below distributor quotes.
Yes — hoop sets and vertical bars can be welded onto the installed stiles, or an LSS rail added, and the assembly re-verified in a fresh calc.
Proven in real facilities
Reference projects are shown by industry, country and scale. Client names are available on request with approval.
National utility projects — 15+ countries
23 documented projects, 2021-2025 · 2025
All standardsEnergy & industrial clients — Global
500+ projects since 2004 · 2004-2025
Full compliance docsLargest single order — Malaysia
60 units in one project · 2021
HDGGet Your No-Cage Quote
Talk to an Engineer
Send your height — get a no-cage fixed ladder quote in 24 hours, free drawing review.
